The STM32F030CCT6 is a mainstream microcontroller based on the Arm Cortex-M0 core with 256 Kbytes of Flash memory and 48 MHz CPU frequency. It belongs to the STM32F0 family and is suitable for a variety of application scenarios such as application control and user interfaces, handheld devices, A/V receivers and digital TVs, PC peripherals, gaming and GPS platforms, industrial applications, PLCs, inverters, printers, scanners, alarm systems, video intercoms and HVAC.

STM32F030CCT6 Key Features

Core: 32-bit Cortex-M0 CPU up to 48 MHz.

Memory: 16 to 256 Kbytes of Flash memory, 4 to 32 Kbytes of SRAM with hardware parity.

Power Management: Supports 2.4V to 3.6V digital and I/O power supplies with power-on/power-off reset and low-power modes (sleep, stop, standby).

Clock Management: Supports 4 to 32 MHz crystal oscillator, 32 kHz RTC oscillator, internal 8 MHz RC oscillator, internal 40 kHz RC oscillator.

I/O: Up to 55 fast I/Os, all mappable to external interrupt vectors with 5V tolerance.

DMA: 5-channel DMA controller.

ADC: A 12-bit, 1.0 µs ADC supporting up to 16 channels with a 0 to 3.6V conversion range.

Timers: 11 timers, including a 16-bit advanced control timer for six-channel PWM output, up to seven 16-bit timers, standalone and system watchdog timers, and SysTick timers.

Communication interfaces: up to two I2C interfaces, up to six USART interfaces supporting master synchronous SPI and modem control; one USART with automatic baud rate detection, up to two SPI interfaces (18 Mbit/s) supporting 4- to 16-bit programmable bit frames.

STM32F030CCT6 Product Attributes

Product Category: ARM Microcontrollers - MCUs

Family: STM32F030CC

Mounting Style: SMD/SMT

Package / Case: LQFP-48

Core: ARM Cortex M0

Program memory size: 256 kB

Data bus width: 32 bit

ADC resolution: 12 bit

Maximum clock frequency: 48 MHz

Number of inputs/outputs: 37 I/Os

Data RAM size: 32 kB

Supply voltage - min: 2.4 V

Supply voltage - max: 3.6 V

Minimum operating temperature: - 40 C

Maximum operating temperature: + 85 C

Data Ram type: SRAM

I/O Voltage: 2.4 V to 3.6 V

Interface type: I2C, SPI, USART

Humidity Sensitivity: Yes

Number of ADC channels: 12 Channel

Processor family: STM32F030

Application Scenarios

The STM32F030CCT6 microcontroller is suitable for a wide range of application scenarios, including but not limited to:

Application control and user interfaces

Handheld devices

A/V receivers and digital TVs

PC peripherals

Gaming and GPS platforms

Industrial Applications

PLCs and inverters

Printers and scanners

Alarm systems and video intercoms

HVAC systems
