The STM32G474CCT6 is a high-performance 32-bit microcontroller (MCU) from STMicroelectronics, based on the Arm® Cortex®-M4 core at up to 170MHz and with an integrated single-precision floating-point unit (FPU), which is suitable for industrial automation, motor control, digital power, medical devices and other applications. high computing demand scenarios.

STM32G474CCT6 core features

High-performance processing power:

Cortex-M4 core, supporting DSP instruction set and FPU floating-point operation, with a computational power of 213 DMIPS.

Adaptive Real-Time Accelerator (ART Accelerator), realising 0-waiting-cycle flash execution and improving code operation efficiency.

Rich storage resources:

512KB Flash (supports ECC error correction, dual Bank read/write)

128KB SRAM (including 32KB CCM SRAM for high-speed data caching)

External Memory Interface (FSMC), supports SRAM, PSRAM, and NOR/NAND Flash expansion.

Advanced Analogue Peripherals:

5 x 12-bit ADCs (0.25μs conversion time, 42 channels)

7 x 12-bit DACs (3 external + 4 internal)

6 x Operational Amplifiers (OPAMPs), supports PGA mode

7 x High-speed Analogue Comparators.

High Precision Timer:

HRTIM (High Resolution Timer) with 184ps resolution for digital power and motor PWM control.

17 timers, including motor control PWM, general-purpose timer, watchdog, etc.

Multiple communication interfaces:

3×FDCAN (Automotive CAN FD)

4×SPI/I2S, 5×USART/UART

USB 2.0 full speed, SAI audio interface

Quad-SPI Flash interface.

Low power consumption design:

operates at 1.71V~3.6V, supports sleep/stop/standby/shutdown modes to optimise energy efficiency.

Industrial Grade Reliability:

Operating temperature -40°C to +85°C, AEC-Q100 compliant (some models) for harsh environments.

STM32G474CCT6 Typical Applications

Motor control: servo drives, BLDC/PMSM motors

Digital power: LLC resonant converters, PFC circuits

Industrial automation: PLCs, HMIs, robotics control

Automotive electronics: on-board chargers (OBCs), body control modules

Medical equipment: portable monitors, ultrasound imaging systems.
