The MKM33Z64ACLL5 microcontrollers are precision metering MCUs with segmented LCDs, based on the Arm® Cortex®-M0+ core. These MCUs provide a low-cost, highly integrated solution for single-chip single-phase, two-phase, and three-phase meters requiring powerful 32-bit processing, precision analogue, security, and HMI functionality.The MKM33Z64ACLL5 provides security through timestamping for active and passive tamper detection, and also supports a high-precision internal voltage reference with low temperature drift. These MCUs come with a comprehensive support suite, including reference designs. Typical applications include power meters, industrial measurement and sensing, and flow meters (e.g., heat, water, and natural gas).

Product Attributes
Core processor: ARM® Cortex®-M0+
Core specification: 32-bit single core
Speed: 50MHz
Connectivity: I²C, SPI, UART/USART
Peripherals: DMA, LCD, WDT
Number of I/O: 68
Program memory capacity: 64KB (64K x 8)
Program memory type: Flash
EEPROM Capacity: -
RAM Size: 16K x 8
Voltage - Supply (Vcc/Vdd): 1.71V ~ 3.6V
Data Converter: A/D 12x16b, 4x24b
Oscillator Type: Internal
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package/Case: 100-LQFP
Supplier Device Package: 100-LQFP (14x14)

Applications
• Electricity meters
• Flow meters (e.g. heat, water and gas)
• Industrial measurement and sensing
• EV chargers
