The NTMFS4925NT1G is a high performance N-channel power MOSFET designed for high efficiency, low power applications. The device is available in an SO-8FL package with low on-resistance and optimised switching performance.

Product Properties

Manufacturer: onsemi

Product Category: MOSFETs

Technology: Si

Mounting Style: SMD/SMT

Package / Case: SO-8FL-4

Transistor Polarity: N-Channel

Number of Channels: 1 Channel

Vds-Drain-source breakdown voltage: 30 V

Id-Continuous drain current: 16.7 A

Rds On-drain on-resistance: 10 mOhms

Vgs - gate-source voltage: - 20 V, + 20 V

Vgs th-Gate-source threshold voltage: 1.7 V

Qg - gate charge: 10.8 nC

Minimum operating temperature: - 55 C

Maximum operating temperature: + 150 C

Pd-power dissipation: 23.2 W

Channel mode: Enhancement

Configuration: Single

Forward transconductance - min: 52 s

Product Type: MOSFETs

Series: NTMFS4925N

Factory Package Quantity: 1500

Sub Category: Transistors

Transistor Type: 1 N-Channel

Unit Weight: 750 mg

Applications

CPU Power Delivery

DC-DC Converter
