For picture reference, please see the specifications
< >

Commodity Model:2034560003

Trade Name:Board-to-Board and Mezzanine Connectors

Brand:Molex

Particular Year:25+

Package:699POS

Delivery Date:New and Original

Stock: 1500pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
Molex
Model
2034560003
Package
699POS
Describe
Board-to-Board and Mezzanine Connectors Mirror Mezz Conn 5.50mm Conn Hgt Mnt 7 Pair 11 Row

Product Description

The Molex 2034560003 is a high-density, high-performance board-to-board connector that is part of the Mirror Mezz family.Molex Mirror Mezz connectors are stackable mating, size-compatible, male and female independent connectors. These connectors support data rates up to 56Gbps per differential pair for telecom, networking and other applications.Molex Mirror Mezz connectors feature a stitched Ball Grid Array (BGA) design instead of insert moulded BGA attachments. These connectors feature a well-designed terminal structure with excellent mechanical strength and superior electrical characteristics. Typical applications include servers, networking devices, storage, and infrastructure.


2034560003 Device Specifications

Product Category: Board-to-Board and Mezzanine Connectors

Product: Connectors

Number of Positions: 699 Position

Pitch: 1.3 mm (0.051 in)

Number of Rows: 11 Row

Termination Type: Solder

Mounting Angle: Vertical

Stacking Height: 5.5 mm

Current Rating: 1 A

Voltage rating: 30 V

Minimum operating temperature: - 55 C

Maximum operating temperature: + 105 C

Contact Plating: Gold

Contact material: Copper

Housing material: Thermoplastic (TP)
