The NRF5340-QKAA-R7 multi-core system-on-chip (SoC) integrates two fully programmable Arm® Cortex®-M33 processors, several advanced security features, various peripherals and a multi-protocol 2.4GHz transceiver. The transceiver supports low-power Bluetooth, ANT™ and 802.15.4 and allows implementation of proprietary 2.4GHz protocols.

Product Specifications

Type: TxRx + MCU

RF Family/Standard: 802.15.4, Bluetooth

Protocols: Bluetooth v5.1, Thread, Zigbee®

Modulation: -

Frequency: 2.4GHz

Data Rate (Max): 2Mbps

Power - Output: 3dBm

Sensitivity: -97.5dBm

Storage capacity: 1MB Flash, 256kB RAM

Serial Interfaces: ADC, I²S, PWM, SPI, UART, USB

GPIO: 48

Voltage - Supply: 1.7V ~ 5.5V

Current - Receive: 2.6mA ~ 7mA

Current - Transmit: 3.2mA

Operating Temperature: -40°C ~ 105°C

Mounting Type: Surface Mount

Package/Case: 94-VFQFN Double row of exposed pads

Supplier Device Package: 94-aQFN (7x7)

Applications

Professional lighting

Industrial automation

Asset tracking and real time location systems

Medical equipment

Smart homes

Advanced wearables
