The device features a serial peripheral interface and software protocol allowing operation on a simple 3-wire bus. The four bus signals are a clock input (SCLK), a serial data input (SI), a serial data output (SO), and a chip select (CS#). Serial access to the device is enabled by CS# input.

When it is in Dual Output read mode, the SI and SO pins become SIO0 and SIO1 pins for data output.

The device provides sequential read operation on whole chip.

After program/erase command is issued, auto program/erase algorithms which program/erase and verify the specified page or sector/block locations will be executed. Program command is executed on byte basis, or page basis, or word basis for erase command is executes on sector, or block, or whole chip basis.

To provide user with ease of interface, a status register is included to indicate the status of the chip. The status read command can be issued to detect completion status of a program or erase operation via WIP bit.

When the device is not in operation and CS# is high, it is put in standby mode.

The device utilizes Macronix's proprietary memory cell, which reliably stores memory contents even after 100,000 program and erase cycles.

Key Features

• Hold Feature

• Low Power Consumption

• Auto Erase and Auto Program Algorithms

• Provides sequential read operation on whole chip

Specification

Memory type Non-volatile

Memory format Flash

Technology FLASH - NOR

Storage capacity 4Mb (512K x 8)

Memory interface SPI

Clock frequency 86 MHz

Write Cycle Time - Word, Page 50µs, 3ms

Voltage - Supply 2.7V ~ 3.6V

Operating Temperature - 40°C ~ 85°C (TA)

Mounting Type Surface Mount

Package/Case 8-WDFN Exposed Pad

Supplier Device Package 8-WSON (6x5)
