The XCZU47DR-2FFVE1156I Embedded System-on-chip (SoC) is a single-chip adaptive RF platform that meets current and future industry needs. The Zynq UltraScale+ RFSoC family supports all bands up to 6GHz, thus meeting key requirements for next-generation 5G deployments. It also supports direct RF sampling for 14-bit analog-to-digital converters (ADCs) with sampling rates up to 5GS/S and 14-bit analog-to-digital converters (DAC) with sampling rates up to 10 GS/S, both with analog bandwidths up to 6GHz.

Product specification

Architecture: MCU, FPGA

Core processors: Quad-core ARM®Cortex ®-A53 MPCore™ with CoreSight™, dual-core ARM®Cortex™-R5 with CoreSight™

Flash memory size: -

RAM size: 256KB

Number of I/ OS: 366

Peripheral: DMA, WDT

Connection capability: CANbus, EBI/EMI, Ethernet, I²C, MMC/SD/SDIO, SPI, UART/USART, USB OTG

Speed: 533MHz, 1.333GHz

Key attributes: Zynq®UltraScale+™ FPGA, 930K+ Logical Unit

Operating temperature: -40°C ~ 100°C (TJ)

Package/case: 1156-BBGA, FCBGA

Supplier Device Package: 1156-FCBGA (35x35)

Typical application

5G and LTE wireless technology

Remote PHY supports cable TV access to DOCSIS 3.1

Phased array radar/digital array radar

Test and measurement

Satellite communication
