CY8C624ABZI-S2D04 is a high-performance, ultra-low-power and secured MCU platform, purpose-built for IoT applications.

CY8C624ABZI-S2D04 product line, based on the PSoC 6 MCU platform, is a combination of a dual CPU microcontroller with low-power flash technology,digital programmable logic, high-performance analog-to-digital conversion and standard communication and timing peripherals.

Feature

Six power modes for fine-grained power management

Deep Sleep mode current of 7 µA with 64-KB SRAM retention

On-chip DC-DC buck converter, <1 µA quiescent current

Backup domain with 64 bytes of memory and real-time clock

8-MHz internal main oscillator (IMO) with ±2% accuracy

Ultra-low-power 32-kHz internal low-speed oscillator (ILO)

On-chip crystal oscillators (16 to 35 MHz, and 32 kHz)

Two phase-locked loops (PLLs) for multiplying clock frequencies

Frequency-locked loop (FLL) for multiplying IMO frequency

Integer and fractional peripheral clock dividers

Execute-In-Place (XIP) from external quad SPI flash

On-the-fly encryption and decryption

4-KB cache for greater XIP performance with lower power

Supports single, dual, quad, dual-quad, and octal interfaces with throughput up to 640 Mbps

Supports up to 101 segments and up to 8 commons

USB Full-Speed device interface

Two independent SD Host Controller/eMMC/SD controllers

Thirty-two timer/counter/pulse-width modulators (TCPWMs)

Center-aligned, edge, and pseudo-random modes

Comparator-based triggering of kill signals

Two low-power comparators available in system Deep Sleep and Hibernate modes

Built-in temperature sensor connected to ADC

Programmable drive modes, strengths, and slew rates

Six overvoltage-tolerant (OVT) pins

• 1.Is the inventory and price seen on the platform accurate?

  A: all online goods on the shelves can be ordered online, but considering the large liquidity of spot inventory, it is not possible to achieve 100% accuracy at present. In case of any abnormality, you can contact our company online and give the corresponding solution.

• 2.Are all our products genuine?

  A: our self-supporting products are from cooperative domestic and foreign original factories or authorized agents, and the source can be traced to ensure the original and authentic products.

• 3.Can you provide the qualification certificate of the original factory or agent?

  A: at present, our self-employed brands TI，ST，ADI，NXP，LATTICE，CYPRESS，INFINEON，XILINX and other first-line brands. Other channels are the original factory and agency channels. If necessary, we can communicate and confirm according to the specific brand and model.

• 4.Can I make an inquiry through the company's website?

  A: You can inquire through the website, or by phone and email.

• 5.When can I deliver the goods after placing an order? How long will it take to get there?

  A: the delivery date is marked in most commodity information. You can estimate the delivery time of the commodity according to the delivery date. The specific arrival time depends on the warehouse where the commodity is located and the logistics mode you choose.

• 6.Can the company issue an invoice?

  A: you can issue ordinary invoices for individual users or special VAT invoices for enterprise users.
