The ETD630N16P60 Infineon Eco Block Soldered Module is ideally suited for applications where highly robust pressure contact technology is not necessary. Typical applications include drives, power supplies and soft starters. The device offers designers the following advantages: improved terminal design for symmetrical current sharing, and 100% X-ray monitoring of the soldering process for high performance and long product life. The second generation 34mm devices have higher current ratings (up to 240A).

Product Attributes

Construction: Series - SCR/Diode

Number of SCRs, Diode: 1 SCR, 1 Diode

Voltage - Off State: 1.6 kV

Current - On-state (It (AV)) (max): 635 A

Current - On-state (It (RMS)) (max): 700 A

Voltage - Gate Trigger (Vgt) (Max): 2 V

Current - Gate Trigger (Igt) (Max): 250 mA

Current - Non-Repeating Surge 50, 60 Hz (Itsm): 19800 A @ 50Hz

Current - Hold-up (Ih) (Max): 300 mA

Operating Temperature: -40°C ~ 135°C (TC)

Mounting Type: Chassis Mount

Package/Housing: Module

Applications

● Soft starters

● Rectifiers for drive applications

● Short circuit applications

● Power controllers

● Rectifiers for UBS

● Battery chargers

● Static switches

● Bypass switches
