APW8743CQBI-TRG is a High Voltage Dual Channels switching converter designed to provide supply voltages for Tiger Lake(TGL)* VNN and V1P05A application. The device is specially designed to provide high efficiency at lighter loads in the range of 4 to 50mA as the application requires while providing peak currents of up to 500mA.

Features Of APW8743CQBI-TRG

Support wide input voltage range from 5.0V to 22V

1 high efficiency COT Mode with 0.5A output current capability for VNN_BYP

1 high efficiency COT Mode with 0.5A output current capability for V1P05A_BYP

Fixed 500KHz Switching Frequency for each channel

Automatic switch over PWM/PFM Control

Stable with low ESR Ceramic output capacitors

Built VIN and VCC POR Control

Built in Current Limit Protection with Latch off Mode

Built in Under Voltage Protection with Latch off Mode

Built in Over Voltage Protection with Latch off Mode

Built in Over Temperature Protection

Built in Individual EN Control for VNN_BYP & V1P05A_BYP

Built in One POK signal indicator for VNN_BYP & V1P05A_BYP

Built in Individual VID Control for VNN_BYP & V1P05A_BYP

TQFN 3x3-16B package

Applications Of APW8743CQBI-TRG

Notebook

Graphic card

Motherboard
