APGA1602SEC/E/KA is 1.6 x 0.2 mm Right Angle SMD Chip LED Lamp.

- The Hyper Red source color devices are made with AlGaInP on GaAs substrate Light Emitting Diode

- Electrostatic discharge and power surge could damage the LEDs

- It is recommended to use a wrist band or anti-electrostatic glove when handling the LEDs

- All devices, equipments and machineries must be electrically grounded

Specification Of APGA1602SEC/E/KA

Color：Red

Configuration：Standard

Lens Color：Colorless

Lens Transparency：Clear

Millicandela Rating：120mcd

Lens Style：Rectangle with Flat Top

Lens Size：1.60mm x 0.90mm

Voltage - Forward (Vf) (Typ)：2.05V

Current - Test：20mA

Viewing Angle：150°, 120°

Mounting Type：Surface Mount, Right Angle

Wavelength - Dominant：624nm

Wavelength - Peak：632nm

Package / Case：0603 (1608 Metric)

Supplier Device Package：Chip LED

Size / Dimension：1.60mm L x 0.90mm W

Height (Max)：0.30mm

Features Of APGA1602SEC/E/KA

1.6 x 0.9 x 0.2 mm right angle SMD LED, 0.2 mm thickness

Low power consumption

Wide viewing angle

Ideal for backlight and indicator

Moisture sensitivity level: 3

Tinned pads for improved solderability

Halogen-free

RoHS compliant

Applications Of APGA1602SEC/E/KA

Backlight

Status indicator

Home and smart appliances

Wearable and portable devices

Healthcare applications
