SFH4053 is an infrared emitter from OSRAM, part of the CHIPLED series, featuring a 0402 (1005 metric) surface-mount package. This device is suitable for applications such as industrial electronics, optical sensors, automatic control, and consumer electronics, offering high optical power, low forward voltage, and fast response characteristics.

Key Features

Wavelength and Optical Performance

Peak Wavelength: 850nm (suitable for near-infrared sensing)

Radiant Intensity: 7mW/sr @ 70mA (typical)

Radiant Flux: 40mW

Electrical Parameters

Forward Voltage: 1.6V (typical), maximum 2V @ 70mA36

Maximum Forward Current: 70mA (DC)

Switching Speed: Rise/fall time of 12 ns each, suitable for high-speed modulation applications

Package and Mechanical Characteristics

Package Size: 0402 (1.0 mm × 0.5 mm × 0.45 mm)

Viewing Angle: 140° (wide-angle design for enhanced coverage)

Mounting Method: Surface Mount (SMD), suitable for automated production

Operating temperature range: -40°C to +85°C (suitable for harsh environments)

Compliant with RoHS standards, lead-free environmentally friendly design

Applications

- Access Control & Security

- Appliances & Tools

- Eye, face and hand tracking

- Factory Automation
