XC6SLX45T-N3CSG324I support MultiBoot configuration, where two or more FPGA configuration bitstreams can be stored in asingle configuration source. The FPGA application controls which configuration to load next and when to load it.

XC6SLX45T-N3CSG324I include a unique, factory-programmed Device DNA identifier that is useful for tracking purposes, anticloning designs, or IP protection. In the largest devices, bitstreams can be copy protected using AES encryption.

Feature

Multiple efficient integrated blocks

Optimized selection of I/O standards

Staggered pads

High-volume plastic wire-bonded packages

45 nm process optimized for cost and low power

Hibernate power-down mode for zero power

Suspend mode maintains state and configuration withmulti-pin wake-up, control enhancement

Lower-power 1.0V core voltage

High performance 1.2V core voltage

Up to 1,080 Mb/s data transfer rate per differential I/O

Selectable output drive, up to 24 mA per pin

3.3V to 1.2V I/O standards and protocols

Low-cost HSTL and SSTL memory interfaces

Hot swap compliance

Adjustable I/O slew rates to improve signal integrity

High-performance arithmetic and signal processing

Fast 18 x 18 multiplier and 48-bit accumulator

Pipelining and cascading capability

Pre-adder to assist filter applications

DDR, DDR2, DDR3, and LPDDR support

Data rates up to 800 Mb/s (12.8 Gb/s peak bandwidth)

Multi-port bus structure with independent FIFO to reducedesign timing issues

Low noise, flexible clocking

Digital Clock Managers (DCMs) eliminate clock skewand duty cycle distortion

Phase-Locked Loops (PLLs) for low-jitter clocking

Frequency synthesis with simultaneous multiplication,division, and phase shifting

Sixteen low-skew global clock networks

2-pin auto-detect configuration

Broad third-party SPI (up to x4) and NOR flash support

Feature rich Xilinx Platform Flash with JTAG

MultiBoot support for remote upgrade with multiplebitstreams, using watchdog protection
