HS4014 is a highly accurate, fully calibrated automotive-grade relative humidity and temperature sensor with a hydrophobic membrane.

Features

Humidity range: 0% to 100%RH

Automotive grade, AEC-Q100 qualified, Grade 2,-40°C to +105°C

Industrial grade, JEDEC qualified, -40°C to+125°C

Hydrophobic membrane, IP67 rating

Digital I2C output with CRC checksum

RH accuracy: ±1.5%RH, typical (HS4011)

14-bit resolution: 0.04%RH, typical

Independent programmable resolution settings: 8,10, 12, 14 bits

Fast RH response time: 4 seconds time constant,typical

Temperature sensor accuracy: ±0.2°C, typical(HS4011, -10°C to +80°C)

Very low current consumption: 0.3µA average(8-bit resolution, 3.3V supply), 0.62µA average(14-bit resolution, 3.3V supply), one RH andtemperature measurement per second

Excellent stability against aging and volatilecompounds

Highly robust protection from harsh environmentalconditions and mechanical shock

Applications

Climate control systems

Instrumentation

Home appliances

Weather stations

Building automation

HVAC systems

Medical equipment

Data logging systems
