RV1126 is Rockchip's new-generation intelligent vision chip, based on quad-core ARM Cortex-A7 core, built-in 2T NPU, supporting 4K30FPS H.264/H.265 video codec. Based on Rockchip's self-developed ISP2.0 technology, RV1126 can realize multi-level noise reduction, 3-frame HDR, and black light full-color technology features; meanwhile, it has built-in HDAEC algorithms and supports microphone voice array, which effectively enhances the sound acquisition and pickup distance. rv1126 truly starts from the industry's pain points, and meets the dual requirements of security products and AIoT applications for image and sound acquisition.

Key Features

Quad-core ARM Cortex-A7 and RISC-V MCUs

250ms fast boot-up

2.0Tops NPU

14M ISP with 3-frame HDR

Supports 3 simultaneous camera inputs

4K H.264/H.265 video encoding and decoding

Detailed Parameters

CPU

- Quad-core ARM Cortex-A7

- RISC-V MCU

NPU

- 2.0Tops, support INT8/ INT16

Memory

- 32bit DDR3/DDR3L/LPDDR3/DDR4/LPDDR4

- Support eMMC 4.51, SPI Flash, Nand Flash

- Supports fast boot up

Display

- MIPI-DSI/RGB interface, max 1080P60fps

2D graphics acceleration engine

- Support rotation, x/y mirroring

- Support alpha layer blending

- Support zoom in and zoom out

Multimedia

- 14M ISP 2.0 with 3-frame HDR (Line-based/Frame-based/DCG)

- Simultaneously supports 2 sets of MIPI CSI/LVDS/sub LVDS and 1 set of 16-bit parallel port inputs

- 4K H.264/H.265 30fps Video Encoding

  -3840 x 2160@30 fps+720p@30 fps encoding

- 4K H.264/H.265 30fps video decoding

  -3840 x 2160@30 encoding + 3840 x 2160@30 fps decoding

Peripheral Interface

- Gigabit Ethernet interface with TSO (TCP Segmentation Offload) network acceleration

- USB 2.0 OTG and USB 2.0 host

- Two SDIO 3.0 interfaces for Wi-Fi and SD cards

- 8-channel I2S with TDM/PDM, 2-channel I2S
