The LT3645IMSE is a dual-output regulator incorporating a 500mA buck regulator. Its wide input voltage range of 3.6V to 36V makes the LT3645IMSE suitable for regulating power from multiple sources, including 24V industrial supplies and automotive batteries. The device's high operating frequency permits the use of compact and low-cost inductors and capacitors, enabling a very small solution.

Cycle-by-cycle current limiting and frequency foldback provide protection against shorted outputs. Soft start and frequency foldback eliminate input inrush current during start-up.

The linear regulator derives its operating voltage from the VCC2 pin and operates at voltages as low as 1.2V. It delivers 200mA of output current with a typical dropout voltage of 310mV.

Additional features of the LT3645IMSE include <2μA shutdown, short-circuit protection, soft-start, and thermal shutdown. The LT3645IMSE is available in a thermally enhanced 12-pin MSE package.

LT3645IMSE Specifications

Product Type: Switching Regulator

Mounting Style: SMD/SMT

Package/Case: MSOP-12

Topology:    Buck

Output Voltage:    16 V

Output Current:    500 mA

Number of Outputs:    2 Outputs

Input Voltage - Min:    3.6 V

Input Voltage - Max:    36 V

Quiescent Current:    1.4 mA

Switching Frequency:    750 kHz

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +125°C

Series:    LT3645

Input Voltage Range:    3.6 V to 36 V

Quiescent Current:    1.4 mA

LT3645IMSE Applications

• Automotive-grade CMOS image sensors

• Industrial/automotive-grade microcontroller power supplies
