The F280025PNSR is part of the C2000™ family of real-time microcontrollers, a family of scalable, ultra-low latency devices designed to improve the efficiency of power electronics, including but not limited to: high power density, high switching frequency, and support for the use of GaN and SiC technologies. The real-time control subsystem is based on TI's 32-bit C28x DSP core and delivers 100MHz signal processing performance for floating-point or fixed-point code running from on-chip flash or SRAM.

Product specification

Core processor: C28x

Kernel specification: 32-bit

Speed: 100MHz

Connection capability: CANbus, I²C, LINbus, SCI, SPI, UART/USART

Peripherals: Undervoltage detection/reset, POR, PWM, WDT

Number of I/ OS: 39

Program storage capacity: 128KB (64K x 16)

Program memory type: Flash

EEPROM capacity: -

RAM size: 12K x 16

Voltage - supply (Vcc/Vdd) : 2.81V ~ 3.63V

Data converter: A/D 16x12b; D/A 2x12b

Oscillator type: Internal

Operating temperature: -40°C ~ 125°C (TJ)

Mounting type: Surface mount type

Package/housing: 80-LQFP

Supplier Device Package: 80-LQFP (12x12)

Typical application

Industrial motor drive

Motor control

Photovoltaic inverter

Digital power supply

Electric vehicles and Transportation

Induction and signal conditioning
